Dual Battery Solar Charge Controller 10A 20A 30A PWM 12V 24V System Batteries Power Panel Regulator Charger(10A)

Specification:Current: 10A / 20A / 30A (optional)Size: approx. 133*70*35mmSystem voltage: 12V/24V adaptiveMaximum photovoltaic voltage: 41V<;0.2VBoost charging voltage: 14.6V (only for 12V system, if using 24V system, please ×2)Direct charging voltage: 14.5V (only for 12V system, if using 24V system, please ×2)Constant voltage charging voltage: 14.2V (only for 12V system, if using 24V system, please ×2)Float voltage: 13.8V (only for 12V system, if using 24V system, please ×2)Charging recovery voltage: 13.0V (only for 12V system, if using 24V system, please ×2)Adjustment method: PWM<; 10mATemperature Compensation: N/CWorking temperature: -35~+60Feature:Solar Charge Controller for managing battery charging which helps to increase a batteries lifetime by preventing overcharging.Batteries must be 12V or 24V. Controller does not charge a 12V and 24V battery.Built in Industrial Microcontroller.State of charge (SOC) showing battery condition.Pulse Width Modulation with four stages of charging.Short circuit, Reverse current, Reverse polarity, Lightning protection, Overcharge protection.Fine workmanship and good performance.Easy to use.Long service life.Package Included:1pc x Solar Charge Controller Regulator1pc x Manual==========Application : Thermal Controller,Charger Controller,Solar System Controller,Solar Working StationMaximum Current : 30A

• 1.Equipped with against overheating, automatically stops charging, against output short circuit, against ovaer discharging, against reverse polarity connection and Limit the MAX charging current protection, protect circuit safety;
• 2.Complete silence and 24hours intelligent temperature monitoring to prevent dangerous conditions, ensure the safety of users.
• 3.Built-in backlight LCD Screen, real-time monitor and control charging: charging current, generated energy, temperature, battery voltage, and error codes, fast and easy set and debugging parameter;
• 4.It has multiple protection functions, including anti reverse connection, short circuit, high temperature, load overcurrent, etc., to protect the safety of the entire system
• 5.Widely Used，suitable for home, industry, business, etc.
